What is Cogniplane?

Cogniplane is a governed AI platform built for enterprise adoption. Unlike a consumer AI tool, every capability your employees access has been reviewed, approved, and configured by your team. The agent runs inside an isolated session per user, connects only to the data sources your admins have whitelisted, and logs every action to a replayable audit trail.

How it works at a glance

When a user sends a message, Cogniplane selects the right skill, calls the approved tools available to that team, and streams the result with full tool activity visible in the conversation. The agent runtime runs in an isolated process per session — connected to your internal systems only through the MCP gateway, which enforces auth and audit on every call. Admins configure what each tenant can access through the tenant policy and integrations surfaces; the runtime enforces those boundaries, not prompts.

Who uses this documentation

Platform capabilities at a glance

Getting Started

Cogniplane runs in your browser. Your admin will give you a link to your organization's Cogniplane instance. Here's what to expect on your first visit.

Signing in

Cogniplane uses your organization's existing identity provider — the same login you use for other work tools. Click Sign in with your organization, complete the login prompt, and you'll land on the chat interface.

The interface at a glance

The main screen has three areas:

• Sidebar (left) — your past and current sessions. Click any session to return to it.
• Chat area (center) — the conversation. Messages from you appear on the right; Cogniplane's responses and tool actions appear on the left.
• Input bar (bottom) — type your message or attach a file here. Press Enter or click Send.

Personal settings

Your settings area includes two new controls that are useful during day-to-day work:

• Token usage & cost — review your own usage over time, broken down by day and model with estimated spend.
• GitHub authorization — if your organization has installed the GitHub App, you can optionally authorize GitHub as yourself so runtime actions use your identity instead of the app bot.

Starting your first conversation

1. Click "New session"

   Each conversation lives in its own session. Sessions keep your context separate and can be resumed later.

2. Type your question or task

   Be as natural as you like. You can ask a direct question ("What were our top 5 products last quarter?") or describe a task ("Summarize this PDF and list the key action items").

3. Watch Cogniplane work

   You'll see the agent's reasoning and any tool calls in the conversation. Read-only actions (like searching a database) happen automatically. Actions with side effects will ask for your approval.

4. Follow up naturally

   Cogniplane remembers the full conversation within your session. You can ask follow-up questions, correct misunderstandings, or change direction at any point.

Having a Conversation

Cogniplane is designed to feel like talking to a knowledgeable colleague — one that also has direct access to your company's data and tools.

What to ask

Cogniplane handles two types of requests well:

Tips for better results

• Be specific about the goal. "Give me a 3-bullet summary" produces a more focused answer than "tell me about this."
• Mention the data source if you know it. "Check the HR policy database" helps Cogniplane pick the right tool faster.
• It's okay to correct the agent. If the answer is off, say so. Cogniplane will adjust and try again.
• Ask multi-step tasks in one message. Cogniplane handles compound requests — you don't need to break them up.

Understanding the response

Cogniplane responses often include:

• Tool activity — a collapsible card showing which tool was used, what was queried, and what came back.
• The answer — the main response, grounded in the data retrieved.
• Follow-up suggestions — the agent may suggest related questions when they're relevant.

When Cogniplane says it can't help

There are a few reasons Cogniplane might decline or say it's unable to help:

• The data source you're asking about isn't connected yet (talk to your admin).
• The task requires a capability that hasn't been enabled for your team.
• The request falls outside the scope of the active skill.

In any of these cases, Cogniplane will explain what's missing so you can follow up with the right person.

Using Skills

Skills are what give Cogniplane specialized knowledge and behavior. Think of a skill as a mode — when a skill is active, the agent knows how to behave, which tools to use, and what kind of answers to give for that domain.

How skills work

Your admin publishes skills for your organization. Skills might include things like:

• A Sales Intelligence skill that queries your CRM and revenue data
• A HR Policy Advisor skill that searches your HR documentation
• A Contract Analyst skill that reads uploaded documents and flags key clauses
• A Financial Reporting skill that pulls data from your data warehouse

Activating a skill

In most cases, skills are available from the session setup screen or a skill selector in the chat interface. Your admin configures which skills are available to your team.

What a skill changes

When a skill is active, Cogniplane:

• Follows domain-specific instructions for how to behave and what to prioritize
• Gets access to specific tools and data sources relevant to that domain
• Uses terminology and formats that match the skill's context (e.g., financial formatting for a finance skill)
• Knows which actions require approval vs. which can run automatically

If the skill doesn't cover your question

Skills are scoped. If you ask something outside the skill's domain, the agent will let you know. Try switching to a different skill or asking your admin whether a skill for that use case exists or is planned.

Tool Actions & Approvals

To answer questions or complete tasks, Cogniplane uses tools — connections to your company's databases, document repositories, and services. Here's how that looks in practice.

Read-only actions run automatically

Most of what Cogniplane does is read-only: querying a database, searching a knowledge base, reading a document. These actions run automatically and are shown as collapsible cards in the conversation so you can inspect exactly what was queried and what came back.

Actions with side effects ask for approval

If Cogniplane wants to take an action that could change data or run a command, it will pause and show you an approval prompt before doing anything. This applies to:

• Write operations — submitting a form, creating a record, triggering a workflow
• Shell commands — when your admin has enabled command execution for a skill, each individual command is shown for your approval before it runs
• File changes — modifications to files in the agent's workspace

Viewing tool activity

Every tool call is visible in the conversation thread. Click the tool activity card to expand it and see:

• Which tool was used
• What input was sent to the tool
• What the tool returned
• How long it took

This transparency is intentional — you should always know how Cogniplane reached its answer.

Working with Files

Cogniplane can read and analyze files you upload directly in the chat. This is useful when you have a document you want the agent to work with — a contract, a report, a data extract.

Supported file types

Importing from SharePoint and Microsoft

Instead of uploading manually, you can browse and import documents from SharePoint and other Microsoft sources through the file selector. Imported files appear in the session like any other upload and flow through the same PII scanning and artifact handling.

How to upload a file

1. Click the attachment icon in the input bar

   Or drag and drop a file directly into the chat window.

2. Wait for the upload to complete

   A progress indicator shows while the file uploads. Large PDFs may take a few seconds.

3. Ask your question

   Once the file is attached, type your question. Cogniplane will read the file as part of answering. For example: "Summarize the key obligations in this contract" or "What does this document say about renewal terms?"

Files stay in your session

Uploaded files are attached to the current session. You can reference the same file multiple times throughout the conversation without re-uploading. Files are not shared across sessions or with other users.

Artifacts & Previews

When Cogniplane produces a file — a summary, a generated report, a modified spreadsheet, a short script — it saves it to the session as an artifact. Artifacts stay attached to your session, so you can refer back to them later or download them.

Inline preview

Most artifacts can be previewed directly in the chat without downloading. Click Preview on any artifact card to inspect:

• Text, Markdown, and code files — syntax-highlighted; Markdown is rendered as formatted HTML.
• Images — PNG, JPEG, GIF, and WebP render inline.
• PDFs — extracted text is shown in a reading view.

Downloading artifacts

Click the download link on any artifact to save it locally. Download links are short-lived and scoped to you, so you cannot accidentally share an artifact by pasting a link.

Referring to artifacts in the conversation

The agent can read any artifact previously created or synced into your session, not only ones generated in the current turn. If you want to be explicit about which files are in scope for a message, use the artifact selector in the composer to tag them — this is a hint to the agent, not a security boundary.

Rating Answers

Every assistant response has a thumbs-up and thumbs-down control. Use them to tell your admins when an answer was helpful or when something went wrong.

• Thumbs up — the response was useful and correctly grounded.
• Thumbs down — the response was wrong, off-topic, or unsafe. You can add an optional comment.

Ratings roll up in the admin feedback dashboard, where they are used to spot regressions and compare model and skill performance over time. Ratings are private to your tenant.

Scheduled Jobs

If a task should run on a recurring basis — a Monday morning sales digest, a weekly compliance check, a nightly data pull — you can schedule it instead of running it manually every time.

Creating a scheduled job

1. Describe the task in a session

   Run the task once interactively so you can confirm it produces the output you want.

2. Schedule it

   From the scheduled jobs area, create a job with the task prompt, the skill to use, and a cron-style schedule.

3. Review run history

   Each run appears in the job's run history with status, output, and any artifacts produced. You can replay a run to see exactly what the agent did.

Managing Sessions

Every conversation in Cogniplane happens inside a session. Sessions keep context separate — each one remembers its own history, files, and state.

Your session list

The left sidebar shows all your sessions, most recent first. Sessions are auto-named from your first message. Click any session to resume it exactly where you left off — the full conversation history is preserved.

Starting a new session

Click New session at the top of the sidebar. Use a new session when you're switching to an unrelated topic — it keeps your conversation history clean and focused.

Resuming a session

When you return to a previous session, Cogniplane picks up the conversation in full context. You don't need to re-explain what you were working on.

Replaying a session

You can scroll back through any session to review what the agent did, which tools it used, and what it found. This is useful for audit trails and for picking up where you left off after time away.

Platform Overview

As an admin, you control how Cogniplane behaves for your organization. You choose the runtime provider, publish skills that define what the agent knows and can do, connect data sources via MCP servers, configure the tenant policy and PII protection, and manage who has access.

What admins manage

The Admin Workbench

All admin tasks happen in the Admin Workbench — a dedicated interface accessible only to users with admin or owner roles. Reach it from the user menu in the top right corner of Cogniplane.

Architecture in brief

Cogniplane runs a dedicated agent runtime per user session. When a user starts a session, the platform launches an isolated process with the compiled configuration for that skill. The runtime connects to your MCP servers through an HTTP gateway that enforces auth and audit on every tool call. This means:

• Sessions are fully isolated — no cross-session state leakage
• Tool calls are logged and auditable on every request
• Configuration changes are staged and applied safely — existing sessions are unaffected
• Multi-tenant deployments use PostgreSQL row-level security to prevent data cross-contamination at the database layer

Security architecture for reviewers

For security teams doing a formal review, here is where the controls live:

Deployment & Hosting

Cogniplane is currently deployed with a split frontend/backend topology designed to keep the user-facing application fast while keeping the backend and stateful services close together.

Current production layout

Region placement

The backend and stateful services are colocated in us-east-2:

• AWS ECS and the Application Load Balancer run in us-east-2
• AWS S3 runs in us-east-2
• PostgreSQL runs in the same region
• Redis runs in the same region

Cloudflare remains the global frontend edge, while the application control plane and data services stay concentrated in a single backend region.

Backend DNS and proxying

The backend uses a custom DNS name that points via CNAME to the AWS load balancer hostname. Cloudflare can proxy that backend hostname in front of the ALB, which gives Cogniplane two practical benefits:

• DDoS protection and edge filtering in front of the API
• Origin shielding, so end users do not connect directly to the raw load balancer hostname

Request path in production

1. The browser loads the frontend from Cloudflare

   Static assets and the public web surface are delivered from Cloudflare's edge network.

2. The frontend calls the backend through the custom API hostname

   That hostname resolves by CNAME to the AWS load balancer.

3. The load balancer forwards requests to ECS

   The backend service handles auth, sessions, runtime orchestration, SSE streaming, and the MCP gateway.

4. The backend talks to S3, PostgreSQL, and Redis in the same region

   This keeps artifact storage, PostgreSQL, and Redis traffic close to the ECS service and reduces cross-region latency.

Runtime Providers

Cogniplane runs sessions on one of two AI runtimes. The choice is a tenant-level setting — every session for that tenant uses the selected provider, and the platform injects the tenant's matching API key at runtime start.

What stays the same across providers

The governance surface is identical on both runtimes:

• Skills, tool allowlists, and approval policy
• MCP server connections and the authenticated MCP gateway
• Audit trail and replayable session history
• PII protection on chat prompts, uploads, and imports
• Per-session runtime isolation and tenant data separation

Deployment modes for a runtime

Each runtime can execute either locally on the backend host or inside an isolated E2B sandbox, depending on the backend configuration:

• Local runtime — the runtime runs in-process alongside the backend. Lowest latency, simplest ops.
• E2B sandbox — each session gets its own isolated sandbox. Session artifacts are synced into the sandbox workspace at the start of each turn so the agent can read them natively (PDFs, images, Office documents, code).

Reasoning and plan streaming

For the Claude Code runtime, intermediate reasoning and plan steps stream into the conversation in real time alongside tool calls, giving users visibility into the agent's thought process before the final answer.

Creating & Publishing Skills

Skills are the primary way you shape what Cogniplane does for your users. A well-written skill gives the agent clear purpose, focused capabilities, and predictable behavior.

There are two ways to create a skill:

• Import from the reviewed marketplace — browse curated AgentSkills bundles and import pinned revisions into your tenant.
• Import a skill bundle manually — upload a ZIP file or point to a GitHub repository containing a packaged skill.

Anatomy of a Skill

Every skill is built from the same core sections. Understanding these sections will help you write skills that behave predictably and give users great experiences.

# ── Metadata ────────────────────────────────────────────────
name: HR Policy Advisor
version: 1.0.0
description: Answers HR policy questions using the company policy knowledge base.

# ── Activation ──────────────────────────────────────────────
# When should this skill be used? This helps the platform and
# users understand when to pick this skill.
## When to use this skill
Use this skill for questions about HR policies, benefits, time-off,
leave entitlements, expense policies, and employee conduct guidelines.

# ── Instructions ────────────────────────────────────────────
# How the agent should behave in this skill context.
## Instructions
You are an HR policy advisor for ACME Corp. Always cite the specific
policy document and section when answering. If a policy is ambiguous,
say so and recommend the user speak with HR directly. Do not speculate
about policies not found in the knowledge base.

# ── Tools ────────────────────────────────────────────────────
# Which MCP server tools this skill can access.
## Tools
- search_knowledge_base: Search the HR policy knowledge base
- query_hr_database: Query structured HR data (read-only)

# ── Workflow ─────────────────────────────────────────────────
# Optional: describe a structured approach the agent should follow.
## Workflow
1. Clarify the employee's question if ambiguous.
2. Search the knowledge base for relevant policy sections.
3. Synthesize a clear, cited answer.
4. Offer to find related policies if helpful.

# ── References ───────────────────────────────────────────────
# External documents or resources the skill should know about.
## References
- Employee Handbook v2024 (linked via knowledge base)
- Benefits Guide 2025 (linked via knowledge base)

Section reference

Writing Your First Skill

The fastest way to create a skill is to prepare a valid AgentSkills bundle, then import it into the Admin Workbench. If you are starting from scratch, write the bundle locally first and use the structure below as your template.

1. Draft the bundle locally

   Create a skill directory with a valid SKILL.md, plus any optional assets/, references/, or scripts/ folders you need.

2. Set the core metadata

   Give the skill a clear name, version (start with 1.0.0), and a one-line description that helps both admins and the platform understand when it should be used.

3. Fill in the Instructions section

   This is the most important part. Write a clear description of the agent's persona, what it should focus on, how it should handle uncertainty, and any hard constraints (e.g., "never speculate about legal obligations").

4. List expected tool access

   Document which MCP server tools the skill expects to use. At activation time, the referenced tools and MCP servers must also be enabled in the tenant policy before they become available to sessions.

5. Add a workflow (optional)

   If the skill should follow a structured approach — for example, always searching the knowledge base before querying the database — describe that sequence here.

6. Import and keep it in draft

   Import the bundle through the Admin Workbench and leave the resulting skill in draft while you review, test, and decide whether to expose it only to beta testers or publish it to everyone.

Testing your skill before publishing

Before activating a skill, use the built-in Skill Workbench to run test conversations against the draft. This lets you verify the skill behaves as expected without exposing it to users.

Importing a Skill Bundle

For more complex skills — or when distributing skills across multiple Cogniplane deployments — you can package and import skills as bundles. A bundle is a structured ZIP file (or GitHub repository) containing the skill definition and any companion files.

Bundle structure

my-skill/
├── SKILL.md          # Required: skill definition
├── README.md         # Optional: human-readable documentation
├── config/
│   └── defaults.json # Optional: default configuration values
└── assets/
    └── prompts/      # Optional: prompt fragments or reference materials

Using the reviewed marketplace

The Skills page can surface a curated marketplace of reviewed AgentSkills bundles. Marketplace entries are pinned to specific Git revisions, so the content you review is the exact content that gets imported into your tenant.

1. Open Skills in the Admin Workbench

   The marketplace appears alongside your manual ZIP and GitHub import options when a marketplace manifest is configured for the deployment.

2. Review the entry metadata

   Each listing shows its review status, tags, publisher, skill version, and the pinned source revision so you can evaluate provenance before importing.

3. Import the skill

   The import creates a tenant-local revision. It does not become active automatically.

4. Activate after review

   Inspect the imported revision, add review notes if needed, then activate it when you are ready for new sessions to pick it up.

Importing a bundle

Reviewing & Activating a Skill

Before users can use a skill, it must be activated. This applies to both skills you write in the workbench and bundles you import.

The skill lifecycle

Activating a skill

1. Open the skill in the Admin Workbench

   From the Skills list, click the skill you want to activate.

2. Review the compiled definition

   Read through the instructions, tool list, and how the skill interacts with the tenant's enabled tools and MCP servers. Confirm everything looks correct.

3. Click "Activate"

   The platform compiles the skill into a runtime manifest and makes it available for new sessions immediately.

Draft vs. published rollout

Activation and visibility are now separate controls. An activated skill can remain in draft so only beta testers can use it, or be marked published so it appears for everyone in the tenant.

• Draft — useful for staged rollout, QA, and internal validation with a limited audience.
• Published — available to all eligible users in new sessions.
• Beta testers — managed from the Admin user management area; they can see draft skills and draft MCP servers that regular members cannot.

Rolling back a skill

Every activation creates an immutable revision. If a newly activated skill has unexpected behavior, go to the skill's Revision History, select a previous revision, and click Activate this revision. The rollback takes effect for new sessions immediately.

Connecting an MCP Server

MCP (Model Context Protocol) servers are how you give Cogniplane access to your company's data and services. Each MCP server exposes a set of tools — named operations the agent can call during a conversation.

Examples of what an MCP server might expose:

• A search_knowledge_base tool that queries a vector search index
• A query_database tool that runs read-only SQL against your data warehouse
• A get_policy_document tool that fetches a specific document from a document store

Before you connect an MCP server

You'll need:

• The HTTP endpoint URL of the MCP server (it must be reachable from the Cogniplane backend)
• Any authentication credentials the server requires (API key, service account token, etc.)
• A list of the tools the server exposes — names, descriptions, and input/output shapes

Adding an MCP server

1. Go to MCP Servers in the Admin Workbench

   Click "Add MCP server".

2. Enter the server details

   Provide a name (used in skill configuration), the HTTP endpoint URL, and a short description of what this server does.

3. Configure authentication

   If the server requires an API key or token, add it here. Credentials are encrypted at rest and never exposed to users or to the agent directly.

4. Run the connection test

   The platform will call the server's discovery endpoint to verify connectivity and retrieve the tool list. If this fails, check the URL, firewall rules, and credentials.

5. Review the discovered tools

   Each tool the server exposes will appear with its name and description. Verify the list is complete and the descriptions are clear — the agent uses these descriptions to decide when to call each tool.

6. Save and assign to skills

   Once saved, the server's tools are available to assign in skill definitions. Go to a skill and add the tools you want that skill to have access to.

Tool descriptions matter

The agent decides which tool to call based on the tool's name and description. Vague descriptions lead to incorrect tool selection. If tool calls aren't firing when you'd expect them to, improving the tool description on the MCP server side is usually the fastest fix.

Integrations

Integrations are the first-class connectors Cogniplane ships with — the systems most enterprise teams already work in. Unlike a generic MCP server you bring yourself, an integration comes with a managed tool set, a per-tenant configuration page, and a built-in OAuth flow. They are managed from a single admin surface so a security review can point to one page to see everything that is enabled.

What ships today

More integrations are registered and on the path to general availability. The admin page lists each one alongside its current status so you can see what is shipping and what is coming.

How an integration is enabled

1. Open Integrations in the Admin Workbench

   You will see every registered integration in one list, with its current state for the tenant.

2. Toggle reads, writes, or both

   Each integration exposes reads and writes as separate switches. Most tenants enable reads first, observe usage, and turn writes on later. Writes always require approval unless the tenant policy explicitly auto-approves them.

3. Provide any tenant-level credentials

   Some integrations need a tenant-installed app (GitHub) or shared credentials. The admin page collects them per integration. Secrets are encrypted at rest and never returned to the UI in clear text.

4. Users authorize as themselves

   For OAuth-style integrations, each user completes a quick sign-in the first time they use a session that needs that integration. Their personal credentials never reach the model — only the agent runtime, scoped per turn.

Tenant Policy

The tenant policy is the single configuration surface that defines what Cogniplane is allowed to do for your organization. Everything an admin needs to shape runtime behavior lives on one page.

What the tenant policy controls

Safe defaults

• Read-only tools (queries, searches, document reads) are auto-approved. No user prompt needed.
• Write tools (creating records, submitting forms, triggering workflows) require approval. The agent pauses and shows an approval prompt before executing.
• Shell command execution is off unless a skill explicitly requires it. When enabled, every command still requires individual user approval.

PII Protection

Cogniplane scans chat prompts, uploaded files, and Microsoft imports for personally identifiable information before the agent sees them, and persists findings for audit. You configure the behavior per tenant.

Modes

Detection layer

Detection combines two providers:

• An LLM-based provider (via OpenRouter) with a retention-aware model choice, used for nuanced detection of names, addresses, and contextual PII.
• A rule-based fallback for structured identifiers (emails, phone numbers, common government IDs) and for when the LLM provider is unavailable.

Where scanning runs

• Chat prompts — every message is scanned synchronously before the model call.
• Uploads and Microsoft imports — scanned as part of the upload path.
• Queued jobs — an async worker scans messages and artifacts that arrived while the provider was unavailable, so audit coverage catches up.

Audit and evidence

Findings are persisted alongside the message or artifact, with the matched categories and positions. Admins reviewing a session can see which parts of each message triggered detection and which mode was applied.

Tenants & Members

Cogniplane is multi-tenant. Each organization (or internal business unit) is its own tenant. Tenants are fully isolated — users, sessions, skills, and data from one tenant are never visible to another.

Roles

Inviting members

1. Go to Members in the Admin Workbench

   Click "Invite member".

2. Enter the user's email address

   The user must have an account in your organization's identity provider. Cogniplane uses your existing SSO — no separate account creation required.

3. Assign a role

   Choose Member, Admin, or Owner. You can change this at any time from the Members list.

4. Send the invitation

   The user will be able to sign in to Cogniplane with their existing organizational credentials. No separate email invitation is required if SSO is configured.

Beta testers

Admins can flag individual users as beta testers from the user management area. Beta testers get access to draft skills and draft MCP servers in new sessions, which makes staged rollouts possible without affecting the wider tenant.

Removing a member

From the Members list, find the user and click Remove. Their active sessions will remain in the system for audit purposes but they will immediately lose the ability to start new sessions.

Tenant-level configuration

Owners manage the following in addition to the runtime and tool controls on the Tenant Policy page:

• Tenant display name
• Organization API key for the active runtime provider — OpenAI key for Codex, Anthropic key for Claude Code
• Tenant GitHub App installation for shared private-repository access
• SSO configuration (identity provider settings)
• Session and audit retention settings

GitHub setup

GitHub access follows a two-layer model:

• Organization GitHub App — installed once by a tenant owner or admin to enable private repository clone and shared repository access for the tenant.
• Optional personal authorization — each user can connect GitHub as themselves from personal settings when they want runtime GitHub actions to run with their own identity instead of the app bot.

Token usage and feedback dashboards

The Admin Workbench surfaces two usage views:

• Token usage — total tokens, estimated cost, daily trends, and breakdowns by user and model.
• Response feedback — aggregated thumbs-up / thumbs-down ratings with a positive-rate summary, daily trend, and per-model breakdown so you can spot regressions.
